CONTACTOR

• Application
• Other, Motor control, power switching, control panels, automation systems, HVAC controls

• Color
• Grey/black with blue actuator

• Conductor Material
• Other, Copper contacts/terminals

• Conductor Shape
• Other, Flat contacts

• Conductor Type
• Other, Solid/Stranded (dependent on wiring)

• Connector Color
• Standard terminal colors (contact blocks in black/white/blue as per model)

• Dielectiric Strength
• 2,200V AC for 1 minute

• Dimension (L*W*H)
• 73mm x 48mm x 80mm (approximate)

• Features
• Compact design, high reliability, long electrical and mechanical life, easy installation, DIN-rail mountable, and finger-safe terminals

• Install Type
• DIN rail or screw mount

• Insulation
• High-grade molded plastic insulation

• Insulation Material
• Other, High-quality thermoplastic (flame-retardant)

• Jacket Material
• Other, Does not apply (Electromechanical device)

• Length
• Standard module size, refer to dimension specification

• Locking Type
• Manual latch for maintenance (option)

• Material
• Thermoplastic housing with copper/silver alloy contacts

• Number of Conductor
• Three main poles (3P); one auxiliary contact (1NO, expandable)

• Operating Temperature
• -5C to +40C

• Product Type
• AC electromagnetic contactor

• Rated Temperature
• -5C to +40C ambient operating temperature

• Size
• S-N12 series standardized size

• Storage Temperature
• -25C to +65C

• Usage & Applications
• Control of motors up to 5.5kW (AC-3), switching of resistive or inductive loads

• Voltage
• Other, AC 220V coil voltage (other coil voltages available), main contact voltage up to 690V

• Weight
• Approx. 550g

• Application
• Other, Industrial, Electrical panels, Power distribution systems

• Cable Type
• Power/Electrical Cable Connector

• Color
• Black

• Conductor Material
• Copper

• Conductor Shape
• Round

• Conductor Type
• Stranded

• Connector Color
• Black

• Core Material
• Copper

• Core Number
• Single Core

• Diameter
• Approx. 28mm

• Dielectiric Strength
• 1500V/min

• Dimension (L*W*H)
• Approx. 68mm x 36mm x 32mm

• Features
• High durability, Secure connection, Easy installation

• Impedance
• 50 Ohm

• Install Type
• Panel Mount

• Insulation
• PVC

• Insulation Material
• PVC

• Jacket Color
• Black

• Jacket Material
• Other, Polyethylene

• Length
• Standard length as per specification

• Locking Type
• Screw Lock

• Material
• High impact thermoplastic & copper alloy

• Number of Conductor
• 1

• Operating Temperature
• -20C to +70C

• Product Type
• Connector

• Rated Temperature
• -20C to +70C

• Shield Material
• Copper Braid

• Size
• Standard

• Storage Temperature
• -25C to +90C

• Tensile Strength
• High

• Usage & Applications
• Power connectors, Industrial machinery, Switchgear

• Voltage
• Other, 250V

• Weight
• Approx. 85g

• Application
• Other, Motor control, Lighting control, HVAC, Industrial automation

• Color
• Black/White

• Conductor Material
• Copper

• Conductor Shape
• Other, Round terminal contacts

• Conductor Type
• Solid

• Connector Color
• Black/White

• Dielectiric Strength
• 2,500V AC for 1 min

• Dimension (L*W*H)
• 54mm x 80mm x 83mm (approx.)

• Features
• High durability, Reliable electrical performance, Compact design, Easy installation, Arc extinguishing chamber for safety

• Install Type
• DIN rail or panel mount

• Insulation
• IEC 60947-4-1 compliant insulation

• Insulation Material
• Other, Moulded plastic (flame retardant)

• Jacket Color
• Black

• Length
• Standard panel mount size

• Locking Type
• Screw terminal

• Material
• High-grade plastic and copper

• Number of Conductor
• 3 main poles + 1 NO auxiliary contact

• Operating Temperature
• -5C to +40C

• Product Type
• AC Contactor

• Rated Temperature
• -5C to +40C operating

• Size
• S-N11 model size

• Storage Temperature
• -25C to +55C

• Usage & Applications
• Switching and controlling electric motors and circuits in industrial panels

• Voltage
• Other, AC 220V/230V, 50/60Hz (coil); Rated insulation voltage 690V

• Weight
• Approx. 420g

• Application
• Other, Motor starting, switching, control of electrical circuits, industrial automation

• Color
• Grey & Black housing

• Conductor Material
• Other, Copper (internal contacts)

• Conductor Shape
• Other, Solid contacts

• Dielectiric Strength
• Rated insulation voltage (Ui) up to 1000 V

• Dimension (L*W*H)
• 205 mm 205 mm 192 mm (approx.)

• Features
• Heavy duty, high reliability, long electrical and mechanical life, easy coil replacement, finger proof terminals, high making and breaking capacity

• Install Type
• Panel mounting

• Insulation
• Class F

• Insulation Material
• Other, High-grade Thermoplastic

• Length
• Standard, as per product design

• Locking Type
• Screw type terminal locking

• Material
• Thermoplastic and Copper

• Number of Conductor
• 3 Pole (Main), 1 NO+1 NC auxiliary contacts

• Operating Temperature
• -25C to +60C

• Product Type
• Contactor

• Rated Temperature
• -25C to +60C operating

• Size
• M300A (as per Eaton standard)

• Storage Temperature
• -40C to +80C

• Tensile Strength
• High durability, industrial grade

• Usage & Applications
• Industrial machinery, motor starters, HVAC, control panels

• Voltage
• Other, 230 - 240V AC (coil voltage), suitable up to 690V AC3 duty

• Weight
• Approx. 9.5 kg

• Application
• Other, Industrial motor control, HVAC, pump operations, lighting circuits

• Color
• Grey/Black

• Conductor Material
• Copper

• Conductor Shape
• Round

• Conductor Type
• Other, Solid/Stranded, as required by terminal

• Core Material
• Copper

• Core Number
• 3

• Dielectiric Strength
• 2500V AC (coil-isolation)

• Dimension (L*W*H)
• Approx. 125mm x 90mm x 105mm

• Features
• Heavy-duty 3 pole contactor, robust construction, reliable switching

• Install Type
• DIN rail or panel mount

• Insulation
• Class B

• Insulation Material
• Other, High-grade plastic

• Length
• Standard module size

• Locking Type
• Screw terminal locking

• Material
• Plastic and metal alloy

• Number of Conductor
• 3 poles + auxiliary contact

• Operating Temperature
• -25C to +55C

• Product Type
• Contactor

• Rated Temperature
• -25C to +55C

• Size
• Standard size for DIL 4M model

• Storage Temperature
• -40C to +80C

• Usage & Applications
• Motor starter, power distribution, automation panels

• Voltage
• Other, 110V AC (Coil Voltage)

• Weight
• Approx. 1.6 kg

• Application
• Other, Motor Control, Power Distribution, Industrial Automation, HVAC, Lighting circuits

• Color
• Grey/Black

• Dielectiric Strength
• 6kV (AC) between open contacts

• Dimension (L*W*H)
• 180mm x 250mm x 155mm (approx)

• Features
• High breaking capacity, AC and DC coil compatibility, Low power consumption, Mechanical durability, Easy installation, Compact design, Suitable for high current loads

• Install Type
• Panel Mounting

• Insulation
• Class B or better

• Insulation Material
• Other, Thermoplastic/Polycarbonate

• Length
• Standard as per manufacturers design

• Locking Type
• Mechanical interlock optional

• Material
• Thermoplastic enclosure, Copper contacts

• Operating Temperature
• -25C to +55C

• Product Type
• 3 Pole Power Contactor

• Rated Temperature
• -25C to +55C

• Size
• 400A Frame Size

• Storage Temperature
• -40C to +70C

• Usage & Applications
• Industrial power switching, Large AC motor starting, Power control panels, Distribution boards

• Voltage
• Other, Up to 1000V AC

• Weight
• 15 kg (approx)

• Application
• Other, Industrial Motor Control, Power Distribution, Automation Systems

• Cable Type
• Not applicable (direct busbar/terminal connection)

• Color
• White/Black

• Conductor Material
• Copper

• Conductor Shape
• Other, Flat/Bar Terminals

• Conductor Type
• Other, Solid/Stranded (for cable connections)

• Connector Color
• White with Black Trim

• Core Material
• Copper

• Core Number
• 3-Pole (Three Phase)

• Diameter
• Terminals suitable for up to 150A cables

• Dielectiric Strength
• Ui = 1000V (According to IEC 60947-4-1)

• Dimension (L*W*H)
• Approx. 125mm x 100mm x 115mm (estimate based on package)

• Features
• Moeller Series, Heavy Duty, High Durability, 3-Pole, With auxiliary contacts

• Install Type
• DIN Rail or Panel Mount

• Insulation
• IEC 60947-4-1 Compliant

• Insulation Material
• Other, Thermoplastic, Flame Retardant

• Length
• Standard Size (see dimensions)

• Locking Type
• Mechanical Latching (optional accessory)

• Material
• Polycarbonate Body with Metal Components

• Number of Conductor
• For 3-Phase Connection

• Operating Temperature
• -25C to +60C

• Product Type
• Contactor

• Rated Temperature
• -25C to +60C (operating)

• Size
• XTCD125 Series Standard

• Storage Temperature
• -40C to +80C (estimated)

• Tensile Strength
• Industrial Grade (Mechanical Durability)

• Usage & Applications
• Industrial Control Panels, Starters, Machinery Automation

• Voltage
• Other, 220V AC (Control), 380/440/660V AC (Operational)

• Weight
• Approx 1.3 kg (noted for XTCD125)

• Application
• Other, Industrial motor control, power switching

• Cable Type
• For copper cable connection

• Color
• White/Gray

• Conductor Material
• Other, Copper with plated terminals

• Conductor Shape
• Other, Round (terminal holes)

• Conductor Type
• Other, Stranded/solid compatible

• Connector Color
• White/Gray

• Core Material
• Copper

• Core Number
• 3 main + 2 auxiliary contacts

• Dielectiric Strength
• Rated for industrial voltage isolation

• Dimension (L*W*H)
• Approx. 85 x 45 x 95 mm

• Features
• High performance, compact design, easy installation, reliable operation

• Install Type
• DIN Rail Mounting

• Insulation
• High dielectric thermoplastic

• Insulation Material
• Other, Thermoplastic

• Length
• Standard OEM size

• Locking Type
• Screw terminal

• Material
• Engineering thermoplastic and metal alloy

• Number of Conductor
• Depends on terminal configuration (Aux & Power

• Operating Temperature
• -25C to +60C

• Product Type
• AC Contactor

• Rated Temperature
• -25C to +60C

• Size
• Standard industrial contactor

• Storage Temperature
• -40C to +80C

• Usage & Applications
• Motor control circuits, AC switching, industrial automation

• Voltage
• Other, 440V AC

• Weight
• Approx. 500-650 g

• Application
• Other, Motor control, switching of electrical circuits, industrial automation

• Color
• Gray/Black with red ABB strip

• Conductor Material
• Other, Copper terminals

• Dielectiric Strength
• 6 kV (50 Hz for 1 min)

• Dimension (L*W*H)
• 203 x 140 x 160 mm (approximate)

• Features
• AF technology, Built-in auxiliary contacts, Wide control voltage range, High performance and reliability, With mounting kit included

• Install Type
• Panel mount (mounting kit provided)

• Insulation
• IP20 (finger safe)

• Insulation Material
• Other, High-grade thermoplastic housing

• Length
• Standard size as per ABB AF190-30-11-13 (exact length not specified)

• Locking Type
• Screw terminal

• Material
• Thermoplastic enclosure, metal frame

• Operating Temperature
• -25C to +60C

• Product Type
• Contactor with mounting kit

• Rated Temperature
• -25C to +60C (operation)

• Size
• AF190-30 standard (Approx. 203 mm height)

• Storage Temperature
• -40C to +70C

• Usage & Applications
• Motor starters, power control circuits, industrial panels

• Voltage
• Other, 100-250V DC (control supply voltage)

• Weight
• Approx. 4.6 kg
